Outdoor Access Control Reader

Understanding the Outdoor Access Control Reader

• High-security standalone access control keypad with proximity card reader

• Supports up to 10,000 users (Hardware) and 500 App users

• Multiple access modes: PIN, Card, or PIN + Card

• Compatible with EM & EM+Mifare cards

• Weatherproof IP66-rated metal body – ideal for harsh outdoor UAE conditions

• Wide voltage support: 12–18V DC

• Low power consumption (Idle ≤ 60mA / Active ≤ 150mA)

• Advanced Wiegand input & output for system integration

• Adjustable relay output time: 0–99 seconds

• 2 Amp lock output load – supports electric strikes & magnetic locks

• Designed for villas, offices, warehouses, parking entrances, labor camps & commercial buildings

• Works perfectly for door access, gate access & barrier control

• Professional installation available after site visit in Dubai & Abu Dhabi

• Ideal for new installations and replacement of old systems

📦 What’s Included (In the Box)

• Metal Access Control Keypad with Card Reader

• Built-in Controller & Relay

• Mounting Accessories

• Wiring Connector Set

• User Programming Guide

⚙️ Key Technical Specifications

• User Capacity:

  • Common Users: 9,988 (PIN/Card)

  • Visitor Users: 10

  • Panic Users: 2

• PIN Length: 4–6 digits

• Operating Voltage: 12–18V DC

• Idle Current: ≤ 60mA

• Active Current: ≤ 150mA

• Card Technology: EM / EM+Mifare (125KHz / 13.56MHz)

• Read Range: 2–6 cm

• Relay Output: 1 Relay (NO / NC / COM)

• Relay Time: 0–99 seconds (Default 5 seconds)

• Lock Output Load: Max 2A

• Wiegand Interface: 26–44 bits / 56 & 58 bits supported

• PIN Output: 4-bit, 8-bit (ASCII), 10-digit Virtual Number

• Protection Rating: IP66 Waterproof

• Operating Temperature: -30°C to +60°C

• Humidity: 0% – 98% RH

• Body Material: Zinc Alloy Metal

🏗️ Installation & Support in UAE

• On-site inspection before installation

• Professional installation available in Dubai & Abu Dhabi

• Suitable for residential, commercial & industrial projects

• Technical support for contractors, system integrators & building maintenance companies

What is an Outdoor Access Control Reader?

An outdoor access control reader is a device designed to manage and facilitate entry into secure areas. These devices are often robust and weather-resistant, making them ideal for outdoor use. They utilize various technologies, such as RFID, biometrics, or keypads, to authenticate users. Many facilities need secure access control solutions, and therefore, an outdoor access control reader provides peace of mind for protecting assets and ensuring authorized entry.

Benefits of Using an Outdoor Access Control Reader

The main advantage of an outdoor access control reader is enhanced security. These systems can monitor who enters and exits a premises, thus reducing the risk of unauthorized access. Additionally, they often come with remote management features, allowing users to grant or revoke access from anywhere. This level of control is crucial for businesses, schools, and residential properties that prioritize safety and security.

Installation and Maintenance Considerations

Installing an outdoor access control reader involves considering factors such as location, power supply, and connectivity. It's crucial to place the reader in a spot that minimizes exposure to extreme weather, yet remains accessible. Regular maintenance is also essential to ensure the system functions correctly. Keeping the device clean and checking connections can prevent technical issues, so proper care will prolong the life of the outdoor access control reader.
